Specification

Horizontal adjustment: stroke 240mm (10mmx24)
Height / rake adjustment: adjust range ±65mm, rake adjustable ±14°;
Backrest adjustment: adjust range 80°＋41°
Head restraint adjustment: adjust range 75mm (25mmx3)
Seat size（length x height x width） 550mmx970mmx485mm
Seat cushion height（work state）265 mm, seat cushion width 485mm, seat cushion depth 460mm
Backrest height 520mm, backrest width 480mm
Connect size（L/RxF/B）216mmx295.5mm
