Specification

Horizontal adjustment: stroke 200mm (10mmx20)
· Weight adjustment: Automated up to 130kg (40~130kg), air pressure 0.3~0.7Mpa (air pressure of supply 0.7~0.9Mpa)
Pneumatic suspension function: stroke ±30mm
Height / rake adjustment: adjust range ±65mm, rake adjustable ±14°;
Backrest adjustment: adjust range 80°＋41°
Head restraint adjustment: adjust range 75mm (25mmx3)
Seat size（length x height x width） 550mmx1050mmx485mm
Seat cushion height（work state）235mm, seat cushion width 485mm, seat cushion depth 465mm
Backrest height 630mm, backrest width 485mm
Connect size（L/RxF/B）216mmx295.5mm;216mm x 280;216mm x 320
