Specification

Horizontal adjustment: stroke 200mm (10mmx20)
Height / rake adjustment: adjust range ±65mm, rake adjustable ±14°;
Backrest adjustment: adjust range 80°＋41°
Head restraint adjustment: adjust range 75mm (25mmx3)
Turntable: 360°（90°X4）
Seat size（length x height x width） 550mmx1055mmx485mm
Seat cushion height（work state）345mm, seat cushion width 485mm, seat cushion depth 460mm
Backrest height 520mm, backrest width 480mm
Connect size（L/RxF/B）372mmx303mm
