Specification

Horizontal adjustment: stroke 200mm (10mmx20)
Weight adjustment: Automated up to 130kg (40~130kg),
Pneumatic suspension function: stroke ±40mm
Height / rake adjustment: adjust range ±65mm, rake adjustable ±14°;
Backrest adjustment: adjust range 80°＋41°
Head restraint adjustment: adjust range 75mm (25mmx3)
Seat size（length x height x width） 550mmx1080mmx500mm
Seat cushion height（work state）245mm, seat cushion width 485mm, seat cushion depth 465mm
Backrest height 630mm, backrest width 480mm
Connect size（L/RxF/B）216 mmx295.5mm
Integrated with seat air compressor
Integrated with 4 point safety belt
